HMC100 High Performance CNC Horizontal Machining Center

Rosnok’s HMC100 redefines CNC horizontal machining center capability with enhanced rigidity, extended machining envelopes, and exceptional part handling stability. This machine features a robust column design and reinforced base casting to minimize vibration and maintain accuracy under full load. An optional dual-pallet changer is available to reduce idle time, enable parallel setup during machining, and significantly boost overall productivity in high-mix, high-volume production environments.

HMC100 High Performance CNC Horizontal Machining Center

HMC100 Specifications

Worktable Size: 1000*1000 mm
Max Worktable Load: 3000 KG
X/Y/Z Axis Travel: 2000/1000/1500 mm
Spindle Speed: 6000/8000 rpm
Spindle Taper: BT50
Tool Magazine: 24/40 Tools (ATC)
Positioning Accuracy: 0.01 mm
Main motor power: 18.5/22 kW
